Frame |
Hardtail, aluminum |
Front brake |
Hayes, Dominion A4, four-piston, hydraulic disc brake |
Suspension fork |
RockShox, JUDY GOLD RL, 120 mm travel |
Rear brake |
Hayes Dominion A4, four-piston, hydraulic disc brake |
Handlebar |
HoheAcht, 31.8 mm, width 720 mm, bend 12°, Rise 15 mm, aluminum, black |
Brake disc front |
Hayes, D-Series, 203 mm, IS 6-hole |
Stem |
HoheAcht, 40 mm, 60 mm, ±7°, aluminum, black |
Brake disc rear |
Hayes, HR D-Series, 180 mm, IS 6-hole |
Grips |
Ergon, GE10 Evo, 135 mm |
Saddle |
Fizik, Antares R7 |
Headset |
ACROS, zs44, zs56, industrial bearings, Stem Cap SP-Connect |
Seatpost |
Limotec, B3 Dropper SP, 40+60mm, 31.6 mm, 10 mm offset, aluminum |
System wheel |
FW: SUNRinglé , Düroc SD37 Expert 29'', aluminum, black, TLR | Front light |
M-WAVE, Atlas K 50, StVZO battery light set, high-performance LED, 42 lm |
RW: SUNRinglé, Düroc SD37 Expert 27.5'', aluminum, black, TLR |
Rear light |
M-WAVE, Atlas K 50, StVZO battery light set, high-performance LED, 6 lm |
|
Wheel size |
FW ws29, RW ws27.5 |
||
Tyres |
FW: Schwalbe, Nobby Nic Evo, 29'' x 2.6'' (65-622) |
Battery lock |
ABUS, BLO SHI IT2 XPLUS |
RW: Schwalbe, Rocket Ron Evo, 27.5'' x 2.6'' (65-584) |
Pedals |
Marwi, SP-2160, AL-6061 Extrusion T6 |
|
Front wheel hub |
SUNRinglé, Düroc SD37 Expert 29'', Disc, 15 x 110 mm, Boost | ||
Rear hub |
SUNRinglé, Düroc SD37 Expert 27.5'', Disc, 12 x 148 mm, Boost | Motor |
Shimano Steps, DU-EP8, 25 km/h, 85 Nm, mid-motor |
Sprocket |
SRAM, Eagle, CS-PG-1210, 12-speed, 11-50 teeth |
Battery |
Shimano Steps, BT-E8036, 630 Wh, integrated |
Chain |
SRAM, SX Eagle 12 S |
Display |
Shimano Steps, SC-E7000, Bluetooth, ANT Private |
Crankset |
Chainring Shimano Steps, SM-CRE80, 36 teeth, steel/aluminium |
Charger |
Shimano Steps, EC-E6002, 2 A |
Crank arm set Shimano Steps, FC-EM600, 170 mm |
Weight |
From 23.6 kg |
|
Derailleur |
SRAM, NX Eagle, RD-NX-1-B1, 12-speed derailleur, freewheel |
||
Shift lever |
SRAM, NX Eagle, TRIGGER, SL-NX1-PA-B1, 12-speed |
Max. permissible weight |
130 kg |
General product information: Prices and colors are subject to change. TechniBike reserves the right to replace named components from one manufacturer with equivalents from another well-known manufacturer if they are not available. The weights of the bikes are based on painted pre-production frames at the time of publication, the actual weight may also vary.
| Frame size (cm) | 42 | 46 | 50 |
| Seat tube (mm) | 420 | 460 | 500 |
| Top tube horizontal (mm) | 600 | 640 | 660 |
| Head tube (mm) | 150 | 150 | 150 |
| Wheelbase (mm) | 1186 | 1206 | 1246 |
| Chainstays (mm) | 460 | 460 | 460 |
| Bottom bracket height (mm) | 326 | 326 | 326 |
| Head tube angle (°) | 67 | 67 | 67 |
| Seat angle (°) | 74 | 74 | 74 |
| Stack (mm) | 647 | 647 | 647 |
| Reach (mm) | 418 | 458 | 478 |
| Body height (cm) | 160 - 170 | 170 - 180 | 180 - 195 |
